Quick Details

  • Condition: New
  • Production Capacity: 10-150 Ton/hr
  • Place of Origin: Shanghai, China (Mainland)
  • Brand Name: Zenith
  • Model Number: VSI type
  • Voltage: 380V
  • Power(W): 110KW
  • Dimension(L*W*H): 3300(mm)x1800(mm)x2400(mm)
  • Weight: 10t-21t
  • Certification: CE&ISO, ISO9001:2000
  • Warranty: One Year
  • After-sales Service Provided: Overseas service center available
  • application: ore
  • Guarantee/Warranty: Qualit/ approvals
  • Spare Parts Supply: For Whole Year
  • Test&Installation: Engineer Assigned
  • After-sale service: For Whole Using Life
  • The Machines classification: sand making machine

Packaging & Delivery

Packaging Details Standard Container for sand making machine
Delivery Time 15

VSI sand maker, sand making machine price, Sand Making Machine



1. Most professional sand making machine
2.  Energy-Saving about 20%~35%.
3.Stable performance
4.Most Competitive Price





Product Description

 VSI Sand Making Machine , Sand Maker, sand making machinery



Our Sand Making Machine is especially efficient to crush harder and causticity materials, such as carborundum, emery, and magnesium sand. Zenith B Series Sand Making Machine is one of the most advanced impact crushers nowadays. It introduces high quality roller bearings, which ensure the smooth running of main unit. Personalized design is used in upper cap, sand making machine is easy and convenient to maintain and replace spare parts. Sand Making Machine is our sole patent using

central feeding & central cascade feeding, which can be changed based on customers' needs.



Working Principle of VSI Sand Making Machine , Sand Maker, sand making machinery :



VSI sand making machine equipment lets materials fall into the crusher and are divided into two parts. One part goes into the high-speed-running impeller of the machine, and the other part goes around the impeller. The two parts materials bump and crush fast during the effect of centrifugal force.Then the materials run like swirl, bump and rub to each other again and again.The finished products go out from the bottom of the machine, and users can get the requested products size after screening by vibrating screen.



Sand Making Machine Features:



1. The structure is simple, and the operating cost is low.
2. High efficiency, and low consumption.
3. Sand Making Machine is slightly influenced by the humidity of material, and the max humidity is 8%.
4. Sand Making Machine is more suitable for crushing mid-hardness materials and high-hardness materials.
5. Its product is cubic, and the density of piling up is high and the iron pollution is low.6. The working noise is less than 75 decibels and dust pollution is little











B Series Sand Making Machine Technical Data:



ModelB-7615DRB-8522DRB-9532DRB-1145DR
Throughput Capacity (t/h)Cascade and central feeding150~280240~380350~540500~640
Central feeding70~140120~200180~280250~360
Max.Feeding dimension (mm)Soft material<35<40<45<50
Hard material<30<35<40<45
Rotation speed(r/min)1700~19001500~17001300~15101100~1310
Double motor power (kw)110~150180~220260~320400~440
Overall dimension (LxWxH)(mm)4100×2330 ×23004140×2500 ×27004560×2600 ×29005100×2790 ×3320
Weight(t)8.611.817.527.5
Power380v,50Hz
Labrication SystemDouble pump motor power2X0.31kW
SafetyAltemative double pump oil supply;machine stops automatically without oil flow or oil pressure.water cooling,motor warm start in winter.
Overall dimension (LxWxH)820X520X1270
Gasoline tank heating power

2KW



Buyer Feedback

zenith mining help me construct this crushing line, which adopts advanced equipment selection, scientific and rational, and intelligent control without much trouble; at the same time, due to better grain type and high quality aggregate, so down-customers are particularly satisfied with stone. So far, I am very satisfied with that daily profit is nearly 100 thousand yuan.
------------Mr. sayed, person in charge of Sand and gravel field


we compared to a number of manufacturers before because large the production line, finally we purchased this equipment to use about a long time from ZENITH, I am satisfacted with ZENITH two aspects: 1. the equipment has good wear-resistant parts and long service cycle; 2.technical personnel of after sales service department not only solve the machine failure in time, but also send professional peson to give equipment instructions, guidance. Besides, they assist in the training of basic troubleshooting knowledge and maintenance skills.---------Mr. renato, The large stone Co., Ltd. partner


We used to domestic small factory equipment before, while we replace the host device again within two years, which led to high maintenance costs. We are learning zenith mining group has most advantages in the aspects of mining after the market investigation, so we buy two sets of single cylinder cone crusher and one jaw crusher with this cooperation, from signing the contract to put into operation with less than a month, zenith mining group is impressing me deeply, not only equipment of good quality and service efficiency is very high. Our project will continue to cooperate with zenith mining group later.
------------Clients From South Africa



We originally plan to purchase powder, but then we purchase 3 sets of equipment when we see the equipment of ZENITH at the customer site with good on-site feedback on convenient technical solutions, sales process and after-sales service. ZENITH brand is really good and can represent Shanghai quality! -----------Clients From Zimbabwe


ZENITH is our old friend and partner. The first equipment we purchase when we newly establish Shanghai research institute is just from ZENITH; both the quality and service are excellent, otherwise we cannot cooperate with them for over 10 years. For the past decades, our company has been always in progress and ZEITH equipment is also continuously upgraded from YGM series to MTM trapezoid mill with improved single-machine yields. As the old saying goes --- only win-win cooperation is sustainable, our cooperation with ZENITH can be mutual-beneficial and enduring coalition.
-----------Clients From Indonesia

Company Information

ABOUT US



Shanghai Zenith Mining and Construction CO., LTD is one high-tech enterprise, which involves R&D, production, sales and service as well. In the past 20 years, we devote to producing mining equipments, sand making machines and industrial grinding mills, offering expressway, rail way and water conservancy projects the solution of making high grade sand and matched equipments.




The head office of Zenith is in Shanghai- the international financial centre. Here we have modern production base of 2.3 million square meters, professional R&D institution and technology team, which make us world-class company. Here all Zenith machines are designed produced, assembled and texted according to the ISO9001:2008.




Till now, our products are sold to 130 countries, being the popular equipments in global crushing and grinding industry. With the development of our Zenith, we would like to help more and more customers start their business in mining and construction industries, offer them the best solution, much more advanced machinery and better service.





Packaging & Shipping

Ways of Packing:
1.Sand blasting, coat with high quality paint;
2.Product wrap by PP-Bubble
3.Load container, Spear Parts in wooden case.



Transportation:
1. By sea Freight;
2. MSK/MSC/APL/EMC/WANHAI/KLINE
3. We will remind you before boat arrival



Certifications



Our Services

Pre-sales Service:
The wide product range enables us to provide our customers with stand-alone machines or complete processing plants. Based on our customers’ request and budget, our experts make efficient, reliable solutions. Following customers’ order we produce strictly, what’s more, before placing the order every customer has the chance to visit zenith working machines or complete plant in the site.


To ease the trip for every visitor to China, in particular the first-time visitor, we provide FOR FREE all relevant visitor-friendly services including invitation letter preparation, hotel reservation, airport pick-up, incity transportation, and sightseeing guide, etc.

After-sales Service:


Experienced technicians guidance is available on the phone, and on the internet. One or more engineers will be dispatched to the quarry site to help install the customers’ plants. Necessary training about machine daily maintenance to local workers is provided also.


After-Sales department is made of well-trained employees and installation engineers, the installation engineers are special and professional members of Zenith, they are now strategically located home and abroad, working for our customers.



FAQ

1.How is the quality of your products?
Our products are manufactured strictly according to national and international standard, and we take a test on every grinder before delivery.


2.Guaranteed:
If products’quality is not consistent with the description as we described or the promise before you place order, we promise 100% refund.


3.How about price?
Yes, we are factory and be able to give you the lowest price than market one, and we have a policy that “ for saving time and absolutely honest business attitude,we quote as low as possible for any customer, and discount can be given according to quantity”.


4.Service and Payment Terms?
A. We usually accept T/T, L/C;
B. T/T: 30% in advance as down payment, the balance before delivery;
C. We take pictures of finished products before delivery.



Contact us

If you are interested with our products, please don't hesitate to contact us. You can tell me the following questions, Then I can send you accurate quotation soon, including additional discount!





1. Which machine do you need? like stone crusher, grinding mill or beneficiation machine, etc.





2. what is your raw material plan to process? like limestone, granite or inron ore, etc.





3. The capacity you need. Like 100 tones per hour or 2000 tones per day.





4. Your contact information. Both Email and phone number are essential, we can contact you easier.





Now, please click the following contact to send us email !



↓↓↓
